Armored Cable Laying Up Stranding Machine With Xlpe

Basic Information
Place of Origin: Hejian,China
Brand Name: Beyde
Model Number: 1600
Minimum Order Quantity: 1 Set
Price: Negotiate
Packaging Details: Container loading with safety packing
Delivery Time: 90 Days after receive deposit
Payment Terms: L/C, T/T
Supply Ability: 120 Set/Year
Color: Customized Warranty:: 12 Months
PLC: Optional Usage: Stranding
Core: 240mm2 Material: Insulation Wire
Power: 380v Rotating Speed: 50rpm
Name: Laying Up Machine Plc: SIEMENS
Stranding Pitch (mm): 180-3166 Type: Automatic
Certification: ISO Inverter: Japan YASKAWA
High Light:

armored cable laying up stranding machine

,

stranding machine with xlpe

,

cable laying up machine with xlpe

Armored Cable Laying up Machine with XLPE​





1. Application
The machine is used for stranding or armouring all kinds of different cross-section core rubber cable, power cable, control cable and charging pile cable production process.

2.​ Features

2.1 More kind and specification, this series machine can be used extensively, so customers can choose the very laying-up equipment.

2.2 Equipped with retreat-spiralling and non-retreat-spiralling function. The way of retreat-spiralling is retreat-spiralling circle , planet retreat- spiralling and sprocket retreat-spiralling.

2.3 The way of pre-spiralling is manual and automatic, the same to thread reel clamp .And the take-up is axle or non-axle.

3. Technical parameters

Model (Laying-up Machine) CLY-630/3+3 CLY-800/3+3 CLY -1000/3+1+1 CLY -1250/3+1+1 CLY -1600/3+1+1
Diameter of single wire φ5-10 mm φ5-12 mm φ8-20mm φ8-25 mm φ10-35 mm
Maximum stranded conductor OD φ30 mm φ40 mm φ63 mm φ70 mm φ80 mm
Stranding Pitch 50-800 mm 95-1500 mm 200-2000 mm 420-3500 mm 550-5176 mm
Capstan Capstan Wheel Diameter 1000 mm 1200 mm 1800 mm 2000 mm 2500 mm
Maximum Haul-off Force 10 T 12 T 15 T 20 T 25 T
Motor Power 18.5 KW 22 KW 30 KW 37 KW 55 KW
Bobbin Size 630 mm 800 mm 1000 mm 1250 mm 1600 mm
Take-up Bobbin 1600 mm 1800 mm 2000 mm 2500 mm 3150 mm
Maximum Haul-off Linear Speed 60 m/min 60 m/min 34 m/min 28 m/min 21 m/min
Central Height 1000 mm 1000 mm 1000 mm 1000 mm 1000 mm



4. Photos:

Armored Cable Laying Up Stranding Machine With Xlpe 0Armored Cable Laying Up Stranding Machine With Xlpe 1

Armored Cable Laying Up Stranding Machine With Xlpe 2

Armored Cable Laying Up Stranding Machine With Xlpe 3

Beyde Trading Co., Ltd. was established in 1983. Our company is located in the Economic Development Zone of Hejian City, Hebei Province, has been the largest professional manufacturer for wire stranding machine and laying-up machine in North China.

Since 2006, relying on the care and support of our customers, Baohong Machinery has been devoted to the research and development of wire stranding machine and laying-up machine and has made great improvement. Now we have become the only one factory who can develop the production of the JLK rigid stranding machine series to be an assembly line processing in China, and we also have independently developed the JGB Bow skip stranding lines, the CGB Bow skip type cabling lines and the CLY High speed Cradle type Laying-up lines.

Now, Beyde Trading Co., Ltd. ., covers an area of 10000 square meters, production workshop 8000 square meters. Our company has 60 employees, including 10 R & D staffs. Annual output value is over 10 million dollars at present,and has developed into one of the most important Stranding Machine Manufacturer in China.
