Single Screw 90mm Cable Extrusion Line 390 Kg / Hour

Basic Information
Place of Origin: China
Brand Name: Beyde
Model Number: 120
Minimum Order Quantity: 1 set
Packaging Details: container
Delivery Time: 90 days
Payment Terms: L/C, D/A, D/P, T/T
Supply Ability: 200 set/year
Usage: Extruding,copper Wire Extruding Voltage: 380V 50
Application: Conductor Chemical Foam-skin Double Layers Insulation Extrusion Color: According To Customer Requirement
Name: Electrical Wire And Cable Making Machine Power: 22KW AC Motor + Inverter
Dimension: 320*230*300mm Speed: 300M/Min
Extrusion Capacity: 180KG/H Product Name: Cable Extrusion Machine
Warranty: 1 Year Extruding Material: PFA,PVDF,ETFE,PEP,LSZH
High Light:

90mm cable extrusion line


390 kg / hour cable extrusion line


inverter single screw wire extrusion machine

Single - Screw Wire Extrusion Machine 90mm Cable Extrusion Line 390kg / Hour


1. Application


This extrusion line is widely used for PE or PVC insulation layer or jacket on house wire, lan cable and building cable etc with section area 1.5-10 square mm.


Cable Extruder Machine Specification:


This production line contains:lut barrel pay off machine,straighten,main machine,injection machine,control case,tank,double wheel capstan,accumulator,double shaft take up and other equipments.The chosen equipments:copper wire preheater,printer,OD measuring instrument,spark tester and PLC control.


2. Advantages

♦Highly automatic, manpower saving
♦Easy to operate and maintain, start-up friendly
♦Converter applied for adjusting speed, power saving

♦Customization available to meet various customer requirments

Famous Brands Parts:
Motor: Dongguan Motor, Teco, ABB, Siemens
Inverter: Japan Yaskawa, Siemens, Taiwan Teco
Temperature Control Meter: Japan RKC
Auxiliary Relay: Japan Omron
Ammeter and Voltmeter: Taiwan Risesun
Indicator, Switch and Button: Taiwan TEND
Contactor: Taiwan Shihlin
Line Speed Meter: Taiwan FOTEK
Bearing: NSK, SKF


3. Parameters
odel 70X25D mm 75X25D mm 80X25D mm 90X25Dmm 100X25Dmm 120X25D mm 150X25D mm 180X25D mm 200X25D mm
Take up and pay off type End-shaft gantry moving type
Pay off reel 1250mm 2000mm 2000mm 2500mm 2500mm 2500mm 3150mm 3150mm 4150mm
Tention traction 500kg 500kg 500kg 800kg 800kg 800kg 3200kg 3200kg 3200kg
Screw diameter 70mm 75mm 80mm 90mm 100mm 120mm 150mm 180mm 200mm
Screw L/D ratio 25:1Bm 25:1Bm 25:1Bm 25:1Bm 25:1Bm 25:1Bm 25:1Bm 25:1Bm 25:1Bm
Extrusion output 300kg/hr 300kg/hr 350kg/hr 450kg/hr 550kg/hr 800kg/hr 1200kg/hr 1300kg/hr 1600kg/hr
Main motor power 45KW 55KW 90KW 110KW 132KW 132KW 250KW 250KW 315KW
Finished dia. 5-25mm 5-30mm 16-35mm 16-50mm 20-80mm 30-80mm 50-140mm 30-140mm 35-200mm
Tractor type caterpillar
Traction force 800KG 1250KG 1250KG 1250KG 1600KG 2000KG 3200KG 3200KG 3200KG
Cooling device Single layer U type water trough
Length of water trough 20m(before 4m after 16m) 22m(before 4m after 18m) 22m(before 4m after 18m) 22m(before 4m after 18m) 22m(before 4m after 18m) 24m(before 4m after 20m) 32m(before 4m after 28m) 32m(before 4m after 28m) 32m(before 4m after 28m)
Size of water trough 250x230x2 250x230x2 250x230x2 250x230x2 280x230x2 280x230x2 380x400x2.5 380x400x2.5 400x360x2.5
Take up reel 1250 2000 2000 2500 2500 2500 3150 3150 4150
Traction speed 2.3-100m/min 2.3-100m/min 2.3-100m/min 2.3-100m/min 2.3-100m/min 2.3-100m/min 5-100m/min 5-100m/min 0-100m/min

Single Screw 90mm Cable Extrusion Line 390 Kg / Hour 0Single Screw 90mm Cable Extrusion Line 390 Kg / Hour 1


Single Screw 90mm Cable Extrusion Line 390 Kg / Hour 2


4. Technical support

Our engineer team has rich experience working overseas for customer on-site service. This ensure us able to provide our customers widely range of support, such as overseas on-site installation, talent training, long-term technology updating services, etc.

5. FAQ

Q1:What is your main brands for the electrical and mechanical parts?
A:Oversea famous brand such as German siemens motor, Japanese nsk bearing and yaskawa inverter etc.
Q2:What is your difference with other suppliers?
A:What we could offer to other customer is not only the machine itself, also we could offer: factory design, production process design , QC control, talent training, assist machine and raw material offering .

Q3:What's the payment terms?
A:T/T,30% deposit and 70% balance before delivery, can be negotiable also.

Q4:How long the guarantee ?
A: One year and charge for repair in the whole life.

BEYDE is a subsidiary of Hebei HEXING electrical machinery Co., Ltd., a professional manufacturer and exporter of cable equipment. Founded in 1983 by Mr. Chen Yuke, grandfather of current president Mr. Chen Jiuzhang, HEXING has a well-equipped factory with an area of 10,000 square meters located in Hejian, Hebei province, home to the manufacture of cable machinery and equipment. HEXING is a well-known brand in China's cable industry, serving over 70% cable manufacturers in northern China.


BEYDE supplies all types of machines including Laying-up machine, Rigid Stranding Machine, Tubular Stranding Machine, Planetary Stranding Machine and help wire & cable manufacturers lower production cost and ensure quality of final products.


BEYDE was established for export business of HEXING as a result of increasing OEM business of HEXING for many Chinese exporters. With maturetechnological expertise, BEYDE provides cost-effective solutions for wire & cable manufacturers to expand or update their production lines
